Sensirion’s VOC and NOx sensors are designed for precise detection and continuous monitoring of nitrogen oxides and volatile organic compounds. These VOC/NOx sensors are metal oxide (MOX) based and integrate our CMOSens® sensor system onto a single chip. A MOX gas sensor operates with a heated metal-oxide surface whose electrical resistance changes in response to the oxygen concentration on its surface. Oxidizing gases like NOx increase the resistance by adding oxygen, while reducing gases such as VOCs lower the resistance by consuming oxygen through surface reactions. This allows for accurate detection of changing air compositions. Our VOC and NOx sensors are ideal for a variety of applications including air quality monitoring and indoor environmental sensing. Explore our MOX gas sensor portfolio to find the ideal solution for your next product.

Filters
  • Series

    • ESS

      2

    • SEK-SensorBridge

      1

    • SEK-SVMxx

      2

    • SGP30

      1

    • SGP4x

      2

    • SGPC3

      1

    • SVM30

      1

    • ASP1400

      0

    • EK-F5x

      0

    • EK-LD20xx

      0

    • EK-LPG10

      0

    • EK-Px

      0

    • EK-SLF3x

      0

    • EK-SLx

      0

    • LD20

      0

    • LG01

      0

    • LG16

      0

    • LPG10

      0

    • LS32-1500

      0

    • SCC1

      0

    • SCC30-DB

      0

    • SCD30

      0

    • SCD4x

      0

    • SCD4x Gadget

      0

    • SDP1xxx

      0

    • SDP3x

      0

    • SDP5xx

      0

    • SDP6xx

      0

    • SDP8xx

      0

    • SDPxxx cap

      0

    • SEK-SCDxx

      0

    • SEK-SDP

      0

    • SEK-SEN5x

      0

    • SEK-SEN6x

      0

    • SEK-SFAxx

      0

    • SEK-SFMxxxx

      0

    • SEK-SHTxx

      0

    • SEK-SPSxx

      0

    • SEK-STC31

      0

    • SEK-STCC4

      0

    • SEK-STS4x

      0

    • SEN5x

      0

    • SEN6x

      0

    • SENSEVAL-SCB4XV1

      0

    • SENSEVAL-SHT4XV1

      0

    • SFA30

      0

    • SFA40

      0

    • SFC3x00

      0

    • SFC4x00

      0

    • SFC5300

      0

    • SFC5400

      0

    • SFC5500

      0

    • SFC6000

      0

    • SFM3xxx

      0

    • SFM3xxx-AW/D

      0

    • SFM4xxx

      0

    • SFM5xxx

      0

    • SFM6000-OEM

      0

    • SFx filter cap

      0

    • SGD43S-M3-Sx

      0

    • SGM53xx

      0

    • SGM63xx

      0

    • SGM64xx

      0

    • SHT1x

      0

    • SHT2x

      0

    • SHT31 Smart Gadget

      0

    • SHT3x

      0

    • SHT43 DemoBoard

      0

    • SHT4x

      0

    • SHT4xA

      0

    • SHT4xI

      0

    • SHT4x Smart Gadget

      0

    • SHT7x

      0

    • SHT85

      0

    • SHTCx

      0

    • SHTWx

      0

    • SLD3P

      0

    • SLF3S

      0

    • SLF3x

      0

    • SLG

      0

    • SLI

      0

    • SLQ-QT105

      0

    • SLQ-QT500

      0

    • SLS-1500

      0

    • SPS30

      0

    • STC31

      0

    • STC42x

      0

    • STCC4

      0

    • STS2x

      0

    • STS3x

      0

    • STS4x

      0

    • STS4xA

      0
  • Class

    • Evaluation kit

      3

    • Reference design

      2

    • Sensor

      5

    • Accessory

      0

    • Development board

      0
  • Product status

    • Active

      4

    • Last time buy

      2

    • Obsolete

      4

    • Upcoming

      0

    • New

      0

    • Not recommended for new designs

      0
  • Interface

    • I²C

      5

    • Sensibus

      0

    • PWM

      0

    • SDM

      0

    • UART

      0

    • RS232

      0

    • RS485

      0

    • Switch

      0

    • Device net

      0

    • IO link

      0

    • ModBus

      0

    • Analog voltage

      0

    • Analog current

      0
SEN69C
Upcoming

SEN69C

Sensing platform for PM, RH/T, VOC, NOx, CO2 and HCHO measurements

Mass concentration precision
±10 %
Mass concentration range
0 - 1000 μg/m³
Particle size range
PM1.0, PM2.5, PM4 and PM10
Lifetime
> 10 years
Supply voltage
3.15 - 3.45 V
Average supply current
80000 uA
Interfaces
I²C
  • Sensor
  • Particulate matter sensors
SEN68
Upcoming

SEN68

Sensing platform for PM, RH/T, VOC, NOx and HCHO measurements

Mass concentration precision
±10 %
Mass concentration range
0 - 1000 μg/m³
Particle size range
PM1.0, PM2.5, PM4 and PM10
Lifetime
> 10 years
Supply voltage
3.15 - 3.45 V
Average supply current
75000 uA
Interfaces
I²C
  • Sensor
  • Particulate matter sensors
SEN66
New

SEN66

Sensing platform for PM, RH/T, VOC, NOx and CO2 measurements

Mass concentration precision
±10 %
Mass concentration range
0 - 1000 μg/m³
Particle size range
PM1.0, PM2.5, PM4 and PM10
Lifetime
> 10 years
Supply voltage
3.15 - 3.45 V
Average supply current
90000 uA
Interfaces
I²C
  • Sensor
  • Particulate matter sensors
SEK-SEN66
New

SEK-SEN66

Evaluation kit SEN60, SEN65, SEN66

  • All-in-one air quality sensor module
  • RH/T, PM (1, 2.5, 4, 10), VOC and NOx, CO2 outputs
  • On-board algorithms



Includes:

  • 1x SEN66
  • 1x adapter cable
  • 1x jumper wire set
  • 1x adapter cabel Qwiic

1x SEK-SensorBridge required

  • Evaluation kit
  • Particulate matter sensors
SGP41

SGP41

VOC and NOx sensor for indoor air quality applications

Sensor output
Digital 16-bit raw signal
Processed output
0-500 VOC Index
Device-to-device var.
15 - 15 % m.v.
Measurement range
0 - 1000 ppm
Response time(τ63%)
< 10 s
Size (LxWxH)
2.44 x 2.44 x 0.85 mm
Average supply current
3000 uA
Interfaces
I²C
  • Sensor
  • NOx & VOC sensors
SGP40

SGP40

VOC sensor for indoor air quality applications

Sensor output
Two digital 16-bit raw signals
Processed output
0-500 VOC Index
Device-to-device var.
15 - 15 % m.v.
Measurement range
0 - 1000 ppm
Response time(τ63%)
< 10 s
Size (LxWxH)
2.44 x 2.44 x 0.85 mm
Average supply current
2600 uA
Interfaces
I²C
  • Sensor
  • NOx & VOC sensors
SEK-SVM4x

SEK-SVM4x

Evaluation kit SEK-SVM4x for SGP40/SGP41

  • VOC + NOX + RH/T sensor module
  • VOC, NOX, RH and T outputs
  • 3.3 V to 5 V supply voltage

Includes:

  • 1x SVM41 development board (1x SGP41 and 1x SHT40)
  • 1x UART to USB adapter cable (2 meter length)
  • 1x jumper wire set
  • Evaluation kit
  • NOx & VOC sensors
SEN55

SEN55

Environmental sensor node for PM, RH/T, VOC, NOx measurements

Mass concentration precision
±10 %
Mass concentration range
0 - 1000 μg/m³
Particle size range
PM1.0, PM2.5, PM4 and PM10
Lifetime
> 10 years
Supply voltage
4.5 V
Average supply current
63000 uA
Interfaces
I²C
  • Sensor
  • Particulate matter sensors
SEN54

SEN54

Environmental sensor node for PM, RH/T, VOC measurements

Mass concentration precision
±10 %
Mass concentration range
0 - 1000 μg/m³
Particle size range
PM1.0, PM2.5, PM4 and PM10
Lifetime
> 10 years
Supply voltage
4.5 V
Average supply current
63000 uA
Interfaces
I²C
  • Sensor
  • Particulate matter sensors
SEK-SensorBridge

SEK-SensorBridge

Connecting bridge with two sensor ports

- Connect two sensors to one SEK-SensorBridge and evaluate simultaneously - 1.2 V to 5.5 V selectable supply - Power supply up to 250 mA at 5 V Includes: - 1x SEK-SensorBridge - 1x USB connector cable
  • Evaluation kit
ESS-C3
Last time buy

ESS-C3

Development board with VOC sensor SGPC3 and humidity sensor SHTC3

Operating relative humidity range
-
Typ. relative humidity accuracy
-
Typ. temperature accuracy
-
Size (LxWxH)
-
Interfaces
-
Supply voltage
-
Average supply current
-
Protective option
-
  • Reference design
  • Humidity sensors
ESS-C1
Last time buy

ESS-C1

Development board with VOC sensor SGP30 and humidity sensor SHTC1

Operating relative humidity range
-
Typ. relative humidity accuracy
-
Typ. temperature accuracy
-
Size (LxWxH)
-
Interfaces
-
Supply voltage
-
Average supply current
-
Protective option
-
  • Reference design
  • Humidity sensors
