STCC4
Upcoming Available Q2 2025CO₂ sensor with unmatched form factor for indoor air quality applications
<p>STCC4 offers one of the smallest form factors on the market for direct measurement of CO<sub>2</sub>, unlocking new applications previously limited by size and cost constraints. Designed for seamless integration into compact electronic devices, the sensor is a groundbreaking newcomer in the CO<sub>2</sub> sensor market.</p><p> </p><p>Utilizing the latest technological advancements in thermal conductivity sensing, the fully factory calibrated STCC4 provides the accuracy needed for indoor air quality applications at a low current consumption. Both accurate signal compensation and monitoring of relevant indoor environmental parameters are achieved when STCC4 is combined with our industry-leading temperature and humidity sensors. Optimized for high volume assembly through its SMD design and tape & reel packaging, it is suitable for a wide range of applications, including indoor air quality monitors, smart thermostats, air conditioners and much more.</p>
Specification
| CO₂ | |||
|---|---|---|---|
| Specified CO₂ Measurement Range
400 - 5000
| 400 - 5000 | ppm | |
| Accuracy
±100.0 ppm ±10.0 %m.v.
| ±100.0 ppm ±10.0 %m.v. |
| Generic | |||
|---|---|---|---|
| Supply voltage
3.3
| 3.3 | V | |
| Average supply current
850
| 850 | uA | |
| Max. supply current
5
| 5 | mA | |
| Interfaces
I²C
| I²C | ||
| Size (LxWxH)
4 x 3 x 1.2
| 4 x 3 x 1.2 | mm³ |
