SGP41

VOC and NOx sensor for indoor air quality applications

Specification

VOC
Sensor output
Digital 16-bit raw signal
Digital 16-bit raw signal
Processed output
0-500 VOC Index
0-500 VOC Index
Measurement range
0 - 1000
0 - 1000 ppm
Response time (τ63%)
< 10
< 10 s
Device-to-device var.
±15
±15 % m.v.
Limit of detection
< 0.05 ppm of ethanol equivalents or < 10 % of concentration setpoint, whichever is larger
< 0.05 ppm of ethanol equivalents or < 10 % of concentration setpoint, whichever is larger
Switch-on time
1
1 h
On-chip humidity compensation
Yes
Yes
Generic
Supply voltage
1.7 - 3.6
1.7 - 3.6 V
Average supply current
3000
3000 uA
Max. supply current
3400
3400 uA
Interfaces
I²C
I²C
Size (LxWxH)
2.44 x 2.44 x 0.85
2.44 x 2.44 x 0.85 mm³

Downloads

Name Type Date File Size
Datasheet SGP41

12/2021

File

-

Datasheet 12/2021 File -
Compliance of Sensirion’s VOC Sensors with RESET and WELL

04/2023

File

748.3 KB

Application note 04/2023 PDF 748.3 KB
Quick testing guide SGP41

11/2021

File

483.5 KB

Guide 11/2021 PDF 483.5 KB
Arduino driver SGP41

04/2022

Link

-

Software 04/2022 Link -
Embedded drivers SGP41

11/2021

Link

-

Software 11/2021 Link -
Gas index algorithm

12/2021

Link

-

Software 12/2021 Link -
Raspberry Pi drivers SGP41

11/2021

Link

-

Software 11/2021 Link -
How can air quality at home be improved?

04/2022

File

260.1 KB

Application note 04/2022 PDF 260.1 KB
How can I integrate Sensirion’s VOC and NOx sensors into my air purifier?

04/2022

File

249.8 KB

Application note 04/2022 PDF 249.8 KB
How can I make my air purifier smart/efficient?

04/2022

File

215.4 KB

Application note 04/2022 PDF 215.4 KB
Is it possible to map the output of a MOX sensor to a norm?

04/2022

File

258.0 KB

Application note 04/2022 PDF 258.0 KB
What are oxidizing gases?

04/2022

File

214.8 KB

Application note 04/2022 PDF 214.8 KB
What are reducing gases?

04/2022

File

332.0 KB

Application note 04/2022 PDF 332.0 KB
What is a metal oxide (MOX) sensor?

04/2022

File

288.2 KB

Application note 04/2022 PDF 288.2 KB
What is Sensirion’s NOx Index?

04/2022

File

341.2 KB

Application note 04/2022 PDF 341.2 KB
What is Sensirion’s VOC Index?

04/2022

File

300.4 KB

Application note 04/2022 PDF 300.4 KB
Design-in guide SGP4x

08/2020

File

304.4 KB

Guide 08/2020 PDF 304.4 KB
Testing guide SGP4x

03/2021

File

507.9 KB

Guide 03/2021 PDF 507.9 KB
SEK-ControlCenter (all devices)

10/2021

Link

-

Software 10/2021 Link -
STEP file SGP40

10/2021

File

1.3 MB

Drawings/CAD 10/2021 STEP 1.3 MB
REACH and RoHS declaration SGP

02/2024

File

102.5 KB

Certificate 02/2024 PDF 102.5 KB
Flyer SGP4x Chinese

02/2024

File

1005.8 KB

Flyer 02/2024 PDF 1005.8 KB
Gas sensors brochure

07/2021

File

996.5 KB

Flyer 07/2021 PDF 996.5 KB
Indoor air quality brochure

10/2021

Link

7.7 MB

Flyer 10/2021 Link 7.7 MB
SGP4x evaluation kit

10/2020

File

1.7 MB

Flyer 10/2020 PDF 1.7 MB
