Successor product

Name Description Series Category
SEK-SVM40
VOC evaluation kit SGP40 SEK-SVMxx VOC

Specification

VOC
Sensor output
Two digital 16-bit raw signals
Two digital 16-bit raw signals
Processed output
Total VOC in ppb, CO2-eq in ppm
Total VOC in ppb, CO2-eq in ppm
Measurement range
0 - 1000
0 - 1000 ppm
Measurement range (CO₂-eq)
0 - 1000
0 - 1000 ppm
Device-to-device var. (CO₂-eq)
10 - 20
10 - 20 %
Device-to-device var.
15 - 25
15 - 25 %
Switch-on time
24
24 h
On-chip humidity compensation
Yes
Yes
Temperature
Typ. temperature accuracy
0.1
0.1 °C
Operating temperature range
-20 - 85
-20 - 85 °C
Humidity
Typ. relative humidity accuracy
5
5 %RH
Operating relative humidity range
0 - 100
0 - 100 %RH
Response time (τ63%)
8
8 s
Generic
Supply voltage
4.5 - 5.5
4.5 - 5.5 V
Average supply current
49000
49000 uA
Interfaces
I²C
I²C
Size (LxWxH)
39 x 15 x 6.5
39 x 15 x 6.5 mm³
Packaging size
80, 800
80, 800 pcs (Tray)

Technical downloads

Name Type Date File Size
SEK-ControlCenter (all devices)

10/2021

Link

-

Viewer software 10/2021 Link -
Datasheet SVM30

03/2019

File

964.2 KB

Datasheet 03/2019 PDF 964.2 KB
Sample code SVM30

10/2021

Link

-

Software 10/2021 Link -
REACH and RoHS declaration SVM30, SCC3x

02/2024

File

99.5 KB

Certificate 02/2024 PDF 99.5 KB
