Successor product

Name Description Series Category
SDP816-500Pa
Analog DP sensor (±500 Pa), tube connection SDP8xx Differential pressure

Specification

Differential pressure
Accuracy
2
2 % m.v.
Pressure range
-5 - 125
-5 - 125 Pa
Calibration
Air
Air
Generic
Supply voltage
4.75 - 5.25
4.75 - 5.25 V
Average supply current
4300
4300 uA
Max. supply current
5200
5200 uA
Interfaces
Analog voltage
Analog voltage
Size (LxWxH)
44 x 30 x 22.1
44 x 30 x 22.1 mm³

Technical downloads

Name Type Date File Size
Datasheet SDP1000

04/2017

File

245.7 KB

Datasheet 04/2017 PDF 245.7 KB
Burst and overpressure specifications

05/2022

File

95.4 KB

Application note 05/2022 PDF 95.4 KB
Bypass configuration SDP600 and SDP1000

11/2010

File

145.6 KB

Application note 11/2010 PDF 145.6 KB
Handling instructions SDP600 and SDP1000 series

02/2012

File

107.3 KB

Application note 02/2012 PDF 107.3 KB
Calibration certification SDP1000 and SDP2000

08/2010

File

21.6 KB

Certificate 08/2010 PDF 21.6 KB
